型号明细 密封件的公称尺寸及腔体尺寸(単位：mm） 标准
（RN919）标准
（PT114）高压
（PA101）d D H GA GB GC DC d1(参考) GNY- 18 *TC-GNY-18 *PE-GNY-18 18 26 5 6 7.5 2 21 18.5 3.5 *GNY- 20 *TC-GNY-20 *PE-GNY-20 20 28 5 6 7.5 2 23 20.5 3.5 GNY- 22 *TC-GNY-22 *PE-GNY-22 22 30 5 6 7.5 2 25 22.5 3.5 GNY- 25 *TC-GNY-25 *PE-GNY-25 25 33 5 6 7.5 2 28 25.5 3.5 GNY- 28 *TC-GNY-28 *PE-GNY-28 28 36 5 6 7.5 2 31 28.5 3.5 GNY- 30 *TC-GNY-30 *PE-GNY-30 30 40 6 7 9 2.5 34 30.5 4 *GNY- 32 *TC-GNY-32 *PE-GNY-32 32 42 6 7 9 2.5 36 32.5 4 GNY- 35 *TC-GNY-35 *PE-GNY-35 35 45 6 7 9 2.5 39 35.5 4 *GNY- 36 *TC-GNY-36 *PE-GNY-36 36 46 6 7 9 2.5 40 36.5 4 GNY- 40 *TC-GNY-40 *PE-GNY-40 40 50 6 7 9 2.5 44 40.5 4 GNY- 45 *TC-GNY-45 *PE-GNY-45 45 55 6 7 9 2.5 49 45.5 4 GNY- 50 *TC-GNY-50 *PE-GNY-50 50 63 8 9 11.5 3 56 50.5 5 GNY- 55 *TC-GNY-55 *PE-GNY-55 55 68 8 9 11.5 3 61 55.6 5 GNY- 56 *TC-GNY-56 *PE-GNY-56 56 69 8 9 11.5 3 62 56.6 5 GNY- 60 *TC-GNY-60 *PE-GNY-60 60 73 8 9 11.5 3 66 60.6 5 *GNY- 63 *TC-GNY-63 *PE-GNY-63 63 76 8 9 11.5 3 69 63.6 5 GNY- 65 *TC-GNY-65 *PE-GNY-65 65 78 8 9 11.5 3 71 65.6 5 GNY- 70 *TC-GNY-70 *PE-GNY-70 70 85 9 10 12.5 3 76 70.6 5 GNY- 75 *TC-GNY-75 *PE-GNY-75 75 90 9 10 12.5 3 81 75.6 5 GNY- 80 *TC-GNY-80 *PE-GNY-80 80 95 9 10 12.5 3 86 80.6 5 GNY- 90 *TC-GNY-90 *PE-GNY-90 90 105 9 10 12.5 3 96 90.6 5 *GNY-100 *TC-GNY-100 *PE-GNY-100 100 120 12 13 16 3.5 107 100.6 6 *GNY-110 *TC-GNY-110 *PE-GNY-110 110 130 12 13 16 3.5 117 110.6 6 GNY-125 *TC-GNY-125 *PE-GNY-125 125 145 12 13 16 3.5 132 125.7 6 *GNY-140 *TC-GNY-140 *PE-GNY-140 140 160 12 13 16 3.5 147 140.7 6 *GNY-160 *TC-GNY-160 *PE-GNY-160 160 180 12 13 16 3.5 167 160.7 6 *GNY-180 *TC-GNY-180 *PE-GNY-180 180 200 12 13 16 3.5 187 180.7 6
